1. Bed size: Length: 191 ± 3cm; Width: 68 ± 3cm (with the guardrail pulled up)
2. Mattress size: head length: 68 ± 3cm; foot size: 120cm ± 3cm
3. Lifting size: head lift: 0-75 degrees ±3 degrees; height lift: 52-83cm ±3cm; electric motor push rod system.
4. The bedside mattress is equipped with head breathing, and the Confucius mother cushion design can plug the breathing holes to keep the bed surface flat when not in use.
5. Bedrail: Folding aluminum alloy guardrail, the guardrail should be lower than the mattress when put down, and the switch should be placed at the tail without pinching hands.
Aluminum alloy guardrail, designed with 3 locking points to increase the robustness during push, and facilitate maintenance and replacement in the future.
In order to ensure the safety of the operation, the braking mechanism of the guardrail needs to be designed under both sides of the bed mattress to avoid the patient's misoperation.
6. Bed body: There are paper towel roll holders at the head and foot of the bed, and a set of hidden drip racks at the head of the bed for use.
7. Bed wheel: with 4 3" double-piece plastic steel wheels, with central control setting function and 4 adjustment feet.
8. Mattress: thickness 5cm±2cm; high-density foam covered with artificial leather, and the outer cover is soft.
